Krubo 225mm EC Backward Centrifugal Fan with Bracket AHU Datacenter Cooling Fan K-EC225-K230-29

Speed Control:0~10V DC/PWM

Direction of rotation:clockwise,seen on rotor

Impeller material:PA6+GF

Type of protecyion: IP55

Insulation class:B

Mode of operation:continuous operation (S1)

Bearing:ball bearings

Motor protection:self-resetting TOP wired internally

Applications: AHU Datacenter etc.


Product Description

OriginChina
BrandKrubo
Measurement225mm
Voltage230V
Frequency50/60Hz
Speed2950RPM
Current1.26A
IP GradeIP55

Isulation

Grade

B
Guarantee1 year
