Krubo EC (Plug) Fan with Bracket for AHU Ventilation-Air Handling Unit

Size: 190mm - 630mm (diameter )

Voltage Ranges: 115V/220V/230V/380V etc.
Frequency: 50/60Hz

Protection: up to IP68

Operating Temperature Ranges: -25℃- +60 ℃
Material:  Steel and Aluminum for option

Applications: Krubo plug fan is one of the best choice for AHU projects

Krubo DC Axial Fan Cooling Fan for Charging Pile High-power Cooler DC Fan Series

Voltage Range: 12V 24V 48V

Product Diameter Range: 80-200mm

Power Range: 6-258W

Airflow Range: 58-995CFM

Pressure Range: 139-1196pa

Material Frame: Aluminum or Plastic

Material Impeller: Plastic (Flammability:UL94V-0)

Lead Wire: +Red-Black (Sensor) Brown (Control)Yellow

Life time:  up to 70000 Hours (Ball bearing)

Bearing Type: Ball/Sleeve Bearings

Applications:charging pile,  cabinet ventilation,  medical technology,data center, heat exchangers and condensers,greenhouses, decentralized residential ventilation,vertical farming,cooling rooms,Refrigeration and freezer units,etc.

Krubo AC Filter Fan for Enclosure Ventilation & Cabinet Cooling

Diameter: 80mm - 280mm

Voltage Ranges: 24V/48V/115V/220V/230V/380V
Frequency: 50/60Hz

Protection: up to IP68

Operating Temperature Ranges: -25℃- +70 ℃
Material: Plastic , Steel and Aluminum for option

Applications: This rank of filter fans are best choice for electronic cabinet and enclosures ventilation and filter in ICT and the electronics industry

Krubo EC Cooling Fan Hot Sales for Control Cabinet Ventilation

Diameter: 133mm - 300mm

Voltage Ranges: 24V/48V/115V/220V/230V/380V
Frequency: 50/60Hz

Protection: up to IP68

Operating Temperature Ranges: -25℃- +60 ℃
Material: Plastic , Steel and Aluminum for option

Applications:This rank of centrifugal fan are best choice for electronic cabinet and enclosures in ICT and the electronics industry

Krubo AC/DC/EC Double Inlet Centrifugal Fan Series for Solar/Wind Inverter and Converter

Dimension range: 97mm-250mm (rotor diameter)

Voltage Ranges: 220V/230V/400V

Frequency: 50/60Hz

Air flow rate: up to 4020m³/h

Fan speed: adjustable according to customer requirements

Applications: widely used in wind power, frequency converter cabinet, control cabinet, drive module fan, fresh air system, dehumidifier, medical devices, electrolyzer, fuel cell, and renewable energy industriesetc.

Krubo Ventilation Fan Cross Flow Series

Motor Type: Shade-pole motor/BLDC motor

Diameter range: 30mm-150mm (rotor diameter)

Length range: 150mm-1200mm(rotor length)

Voltage Ranges: 12v/24/48VDC 115V/230V

Frequency: 50/60Hz

Air flow rate:12-4250m³/h
Bearing type: Ball bearing

Fan speed: adjustable according to customer requirements

Applications: widely used for space ventilating, especially trench heater,floor convector,wall convector,home ventilation,catering equipment,electronic cooling,heat recovery, etc.

Krubo AC compact Fan Axial Fan for Converter Device Power Module Cooling Fan K-AC17055HB2T

Voltage: 200/240V

Frequency: 50/60Hz

Speed: 2850/3300RPM

Air Flow: 250/293CFM

Power: 46/50W

Current: 0.20/0.22A

Applications: widely used in electronic device, driver module, converter technology, power module,control cabinet, chassis cabinet etc.

Krubo 172*172*51mm  DC compact Fan Axial Fan for Converter Device Power Module Cooling Fan K-DC17251-A24-51

Voltage：24V

Current: 1.35A

Power：32.4W

Speed：5100RPM

Life Time：50000h

Applications: widely used in electronic device, driver module, converter technology, power module,control cabinet, chassis cabinet etc.

Krubo 120*120*38mm DC compact Fan Axial Fan for Converter Device Power ModuleCooling Fan K-DC12038-A24-32

Voltage：14.0~26.4V

Current: 0.46A

Speed：3200RPM

Air Flow：135.90CFM

Bearing: Ball Bearing

Sound: 48dBA

Applications: widely used in electronic device, driver module, converter technology, power module,control cabinet, chassis cabinet etc.

Krubo 200*200*53mm DC Compact Axial Fan K-DC20053-A24-82H

Model：K-DC20053-A24-82H

Voltage：24VDC

Power：220.8W

Speed：8200RPM

Features：70000h，IP22, 9.2A, 200*200*53mm

Application: widely used in electronic devices, drive module, converter technoloy, control cabinet, chassis cabinet etc.

Krubo 172*172*51mm DC Compact Axial Fan K-DC17251-A48-92-68

Model：K-DC17251-A48-92-68

Voltage：48V

Power：60.0W

Speed：9200RPM

Features：70000h，IP68, 3.16A, 172*172*51mm

Krubo 120mm DC Axial Fan K-DC12025-A12-34

Model：K-DC12025-A12-34

Material：Plastic

Voltage：12V

Speed：3400RPM

Current：0.44A

Air Flow：123.9CFM

Bearing：Ball Bearing

Krubo EC Fan Axial Radiator Ran Refrigeration Cooler  K-EC900-W400-10M

Rated voltage: 400VAC

Voltage range:380~480VAC

Life time: up to 30000 hours

Equipped with Air Guide Mesh Cover

Type of protection:IP54

Applications: widely used in refrigeration cooler, air conditioner, cooling condenser, space velitation etc

Krubo 300mm EC Axial Fan K-EC300-S230-23

Model：K-EC300-S230-23

Voltage：230V

Power：155W

Current：1.25A

Speed：2300RPM

Features：IP44, Class B, 3000m³/h, 350Pa, -25~60℃，

Krubo 250mm EC Axial Fan K-EC250-S230-31

Model：K-EC250-S230-31

Voltage：230V

Power：175W

Current：1.35A

Speed：3100RPM

Features：IP44, Class B, 2100m³/h, 255Pa, -25~60℃，

Krubo 250mm EC Axial Fan K-EC250-W230-31

Model：K-EC250-W230-31

Voltage：230V

Power：170W

Current：1.3A

Speed：3100RPM

Features：IP44, Class B, 2150m³/h, 275Pa, -25~60℃，

Krubo 350mm AC Axial Fan K-AC350-S380-23

Krubo K-AC350-S380-23 3~380V AC 169W 350mm 2384RPM AC Axial Cooling Fan

Krubo AC Axial Fan Heating Ventilating and Air Conditioning K-AC450-S400-13

Voltage: 400V

Frequency: 50/60Hz

Speed: 1392/1565RPM

Power: 320/490W

Application: widely used in electronic device, driver module, frequency converter device, power module,control cabinet, chassis cabinet,heating ventilating and air conditioning, etc.

Krubo AC Centrifugal Fan for AHU Datacenter Cooling Fan  K-AC280-R220-13

Voltage: 220V

Frequency: 50Hz

Input Power: 95W

Speed: 1370rpm

Current: 0.45A

Applications: widely used in electronic device, driver module, converter technology, power module,control cabinet, chassis cabinet AHU, datacenter etc.

Krubo AC Centrifugal Fan for AHU Datacenter Cooling Fan K-AC280-R220-25

Voltage: 220V

Frequency: 50Hz

Speed: 2570RPM

Air Flow: 1360m3/h

Current: 0.88A

Power: 203W

Applications: widely used in electronic device, driver module, converter technology, power module,control cabinet, chassis cabinet AHU, datacenter etc.

Krubo 560mm Backward Centrifugal Fan AHU Cooling Fan EC Fan K-EC560-K380-18

Voltage: 380V

Current: 7.5A

Power: 4400W

Speed：1800RPM

 Frequency: 50/60Hz

Applications: widely used in cabinet, air conditioning ,refrigeration, AHU building ventilation, etc.

Krubo 146mm AC Fan Ventilation Blower K-AC146-G230-13

Voltage: 230V

Current: 1.27A

Frequency: 50Hz

Power Input: 295W

Speed: 1350RPM

Applications: widely use in ambulance, press equipment, dehumidifier ,Electric drive, fresh air system, air conditioning purification, air shower, wind power etc.

Krubo EC Blower 146mm Centrifugal Fan Cooling Fan for Industrial Refrigeration K-EC146-D230-26

Voltage: 230V

Speed: 2620RPM

Bearing: Ball bearings

Type of protecyion: IP55

Materials Housing：Sheet steel

Materials Impeller:Galvanized sheet

Applications: widely used in transport engineering, industrial refrigeration etc.

Krubo AC Double Inlet Blower K-AC146-G230-13

Model：K-AC146-G230-13

Voltage：230V

Current：1.27A

Power：295W

Air Flow：1095m3/h

Speed: 1350RPM

Krubo 160mm AC Blower K-AC160-D380-A01

Model：K-AC160-D380-A01

Voltage：380V

Power：708W/1045W

Current：1.3A/3.0A

Speed：2700RPM/3000RPM

Features：IP00,40000hours，F

Krubo 150-B EC Centrifugal Fans Double Inlet K-EC150-D230-19

Model：K-EC150-D230-19

Voltage：230V

Power：180W

Current：1.35A

Speed：1900RPM

Features：IP44, Class B, 1200m³/h, 600Pa, -25~60℃，

Krubo 120mm AC Single Inlet Blower K-AC120-G230-24

Krubo K-AC120-G230-24

Voltage: 230V AC

Current: 0.35A/0.40A

Power: 80W/90W

Speed: 2460RPM/2680RPM

Air pressure: 320Pa/350Pa

IP Rating: IP44

Purification Fan

Krubo Crossflow Fans Air Ventilation KLB-DC301082-Q24

Voltage: 24VDC

Current: 0.36A

Overall Length:

Speed: 2400rpm

Applications: widely used in elevator, floor ventilation, air curtain machine system, heater, high temperature fan

Krubo Crossflow Fans Space Ventilation KPB-AC40290-Q230

Voltage: 310V

Overall Length: 370mm

Speed: 2400rpm

Air Flow: 106m³/h

Noise:38dB

Applications: widely used in elevator, floor ventilation, air curtain machine system, heater, high temperature fan, etc.

Krubo Crossflow Fans Air Ventilation KLL-DC60520-Q24

Voltage: 24VDC

Current: 0.6A

Overall Length: 600mm

Speed: 1800rpm

Air Flow: 330m³/h

Noise:47dB

Applications: widely used in elevator, floor ventilation, air curtain machine system, heater, high temperature fan

Krubo AC Motor Crossflow Fans Tangential Fans Air Ventilation KPA-AC60300-Q220

Voltage：220V

Current: 0.32A

Length: 397mm

Power：41W

Speed：2000RPM

Air Flow: 250m³/h

Applications: widely used in elevator, floor ventilation, air curtain machine system, heater, high temperature fan

Krubo KGD200 Duct Fan

Model：KGD200

Voltage：AC110~240V

Power：180W

Speed：3000RPM

Features：830 m³/h，Duct Fan，Power Line：3cores X0.75²X1.5M，

Krubo KGD150 Duct Fan

Model：KGD150

Voltage：AC110~240V

Power：40W/50W

Speed：2500RPM

Features：630 m³/h，502Pa，Duct Fan， Stepless Speed Regulation,   Intelligent panel;

Krubo KGD100 Duct Fan

Model：KGD100

Voltage：AC110~240V

Power：30W/35W

Speed：3000RPM

Features：260 m³/h，215Pa，Duct Fan， Stepless Speed Regulation,   Intelligent panel;

Krubo Oven Recirculation Fan 36W K-AC6035-A230-16

Voltage: 230V

Frequency:50Hz

Input Power: 36W±10%

Speed:1600RPM±10％

Current:0.3A±10%

Applications:Krubo recirculation fan of Hot and cold air for baking and cooking  ensures uniform temperatures in the appliance, increasing the efficiency of the entire appliance

Krubo Oven Recirculation Fan 58W K-AC6030-A230-22

Voltage: 230V

Frequency:50Hz

Input Power: 58W±10%

Speed:2250RPM±10％

Current:0.51A±10%

Applications:Krubo recirculation fan of Hot and cold air for baking and cooking  ensures uniform temperatures in the appliance, increasing the efficiency of the entire appliance

Krubo Oven Recirculation Fan 45W K-AC6030-A230-21

Voltage: 230V

Frequency:50Hz

Input Power: 45W±10%

Speed:2100RPM±10％

Current:0.51A±10%

Applications:Krubo recirculation fan of Hot and cold air for baking and cooking  ensures uniform temperatures in the appliance, increasing the efficiency of the entire appliance

Krubo Oven Recirculation Fan 32W K-AC6020-M230-17

Voltage: 230V

Frequency:50Hz

Input Power: 32W±10%

Speed:1700RPM±10%

Current: 0.24A±10%

Applications:Krubo recirculation fan of Hot and cold air for baking and cooking  ensures uniform temperatures in the appliance, increasing the efficiency of the entire appliance

KAF series wind powerspecialized motors

Rated Voltage:690V

Frequency:50Hz

Power Range:6/3.5Kw

Rated Speed:1450/710RPM

Efficiency:88%

Rated Current:6.5/5.6A

Connection:A/Y

Protection Grade:IP55

Insulation Level:Class F

Operating temperature:65°C

Applications:widely used in HVAC, wind power,energy saving renovation, also perfectly suited for selective component cooling,and mechanical requirements, such as railway systems or high temperatures in drying plants. etc.

KSME Series Permanentmagnet Motors Permanent Magnet Motors EC Motors for rail transit train air conditioning fan

Rated Voltage:380-450V

Power Range: 0.12~22/22~250KW

Rated speed:1500/1800/3000/6000+

Service factor:1.2

Power factor:0.98

Efficiency:90%~97%

Protection level: Class F

Protection grade:IP55/IP56

Insulation level:Class F/H

Applications:widely used in HVAC, wind power,energy saving renovation, also perfectly suited for selective component cooling,and mechanical requirements, such as railway systems or high temperatures in drying plants. etc.

Krubo Fan 300km/ h -350km/h railway centrifugal fan motor K-AF-90S-4,ZT050-4-BJ2

Voltage: 380V

Frequency:50Hz

Current:2.0A

Input Power: 0.75Kw

Speed:1400RPM

Feature: 300km/ h -350km/ h railway centrifugal fan motor (minus 40 degrees, can be customized minus 50 degrees)

Applications: Rail Transit

Krubo railway axial fan motor for Rail Transit Industry K-AF-80M2-4,56,LSGG-LX

Voltage: 380V

Frequency:52Hz

Current:1.85A

Input Power: 0.65Kw

Speed:1460RPM

Feature:Railway axial fan motor (-40 degrees below zero, can be customized to -50 degrees below zero)

Applications: Rail Transit
